Use these boxes to show or hide columns that you want to compare
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
|
| SLM-Model | SLM-AVO | SLM-AVB | SLM-NVO | SLM-NVH | SLM-AVP | SLM-NHO | SLM-NVT | SLM-SVO | SLM-GVO | SLM-GVOT | SLM-HVO | SLM-LVO | SLM-DVO |
| General Description Typical Applications | ANSI-Dimensional General Service | ANSI-Dimensional General Transfer Close Coupled | General Service High Flow Rates | High System Pressure General Transfer | API 685 Heavy Duty | High Temperature Heat Transfer Service ANSI / ISO-Dim. | Submerged Vertical Tank Installations | Multi-Stage Regenerative Turbine Self Priming | Multi-Stage Centrifugal Pump | Multi-Stage Centrifugal Pump Barrel Design | Multi-Stage Centrifugal Pump High Flow & Head | Screw Pump High Viscosities | Self Priming Centrifugal Pump |
| Configuration/Hydraulics | ANSI | ANSI | ISO | ISO | ANSI | ANSI / ISO | ISO | N/A | N/A | N/A | N/A | N/A | N/A |
| Available Flanges | ANSI 150/300 | ANSI 150/300 | ANSI 150/300 DIN-ISO | ANSI 150 - 2500 DIN-ISO | ANSI 150/300 | ANSI 150/300 DIN-ISO | ANSI 150/300 DIN-ISO | ANSI 150/300 DIN-ISO | ANSI / ISO | ANSI / ISO | ANSI / ISO | ANSI / ISO | ANSI / ISO |
| Mounting Configuration | Long-Coupled | Close-Coupled | Long-Coupled | Long-Coupled | Long-Coupled | Long-Coupled | Flanged | Long-Coupled | Long-Coupled | Long-Coupled | Long-Coupled | Long-Coupled | Long-Coupled |
| Max. Flow | 1000 gpm | 800 gpm | 18000 gpm | 3500 gpm | 18000 gpm | 18000 gpm | 4000 gpm | 180 gpm | 1500 gpm | 1500 gpm | 2500 gpm | 1250 gpm | 2300 gpm |
| Max. Differential Head | 450 ft | 250 ft | 700 ft | 700 ft | 700 ft | 700 ft | 700 ft | 1500 ft | 2400 ft | 1500 ft | 4200 ft | 850 ft | 280 ft |
| Max. Viscosity | 300 cPs | 300 cPS | 300 cPs | 300 cPs | 300 cPs | 300 cPs | 300 cPs | 10 cPs | 30 cPs | 30 cPs | 30 cPs | 3000 cPs | 30 cPs |
| Max. Pressure Rating | 580 psi (PN 40) | 580 psi (PN 40) | 580 psi (PN 40) | 5800 psi (PN 400) | 725 psi (PN 50) | 580 psi (40 bar) | 580 psi (PN 40) | 580 psi (PN 40) | 914 psi (PN 63) | 5800 psi (PN 400) | 1450 psi (PN 100) | 232 psi (PN 16) | 232 psi (PN 8) |
| Temperature Range | -185 to 572 °F (-120 to 300 °C) | -185 to 248 °F (-120 to 120 °C) | -185 to 572 °F (-120 to 300 °C) | -185 to 752 °F (-120 to 400 °C) | -185 to 840 °F (-120 to 450 °C) | -185 to 840 °F (-120 to 450 °C) | -58 to 302 °F (-50 to 150 °C) | -40 to 482 °F (-40 to 250 °C) | -185 to 482 °F (-120 to 250 °C) | -185 to 482 °F (-120 to 250 °C) | -40 to 356 °F (-40 to 180 °C) | -14 to 572 °F (-10 to 300 °C) | -4 to 248 °F (-20 to 120 °C) |
| Number of Stages | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1-8 | 1-6 | 1-6 | 1-6 | 1 | 1 |
| Max Driving Power | 250 HP | 40 HP | 700 HP | 60 HP | 700 HP | 300 HP | 300 HP | 100 HP | 300 HP | 300 HP | 500 HP | 60 HP | |
| Speed Range | 1450 - 3500 RPM | 1450 - 3500 RPM | 1450 - 3500 RPM | 1450 - 3500 RPM | 1450 - 3500 RPM | 1450 - 3500 RPM | 1450 - 3500 RPM | 1450 - 1750 RPM | 1450 - 3500 RPM | 1450 - 3500 RPM | 1450 - 3500 RPM | 0 - 3500 RPM | 1450 - 3500 RPM |
| Suction Inducer Available | Yes | Yes | Yes | Yes | Yes | Yes | Yes | N/A | No | No | No | No | No |
| Heating/Cooling Available | Yes - H1&2 | Yes - H1&2 | Yes - H1&2 | Yes - H1&H2 | Yes - H1&2 | Yes - H1&2 | N/A | Yes - H1&2 | Yes - H2 | Yes - H1&2 | Yes - H2 | Yes - H1&2 | Yes - H2 |
